產品規格列表
|
|
制造商零件號 | 點格式 | 活動區域 | 外形尺寸 | 背光 | 亮度 | 接口 | 控制器IC | 電匯 | 公地 | 注釋 | 備注 | 文件下載 |
| 1.28 | TC128BQG-V14 |
240*240 |
32.4*32.4 |
37.70*35.60*2.73 |
2P | TBD |
4line SPI |
GC9A01 |
/ | ALL |
14 pin |
圓屏 |
點擊下載 |
|
1.5 |
TC154GWQO-V40 |
480*240 |
29.76*22.32 |
37.10*32.50*2.50 |
2P | TBD |
SPI+8 位 RGB Interface |
OTA5182A-C2 |
/ | 6 | 40pin |
|
點擊下載 |
| 1.77 |
TC177CQS-V12 |
128*160 |
31.832*41.42 |
33.3*42.94*2.4 |
2P | TBD |
4w-SPI Parallel |
ST7735S |
/ | 6 |
12 pins solder type |
|
點擊下載 |
| 1.77 |
TC177CQS-V24 |
128*160 |
31.832*41.42 |
33.3*42.94*2.4 |
2P |
TBD |
4w-SPI Parallel |
ST7735S |
with TP |
12 |
24 pins solder type |
|
|
| 1.8 |
TC018CQS-V20 |
128*160 |
28.03 *35.04 |
34.0*43.8*2.4 |
2P |
TBD |
8080 8-bit Parallel |
ST7735S |
/ | 12 |
20 pins solder type |
|
|
| 2.0 |
TC020BQI-V10 |
320*240 |
40.80*30.60 |
46*40.9*2.53 |
3P |
TBD |
4W-SPI |
ILI9342c |
/ | 12 |
10PIN |
|
|
| 2.0 |
TC020GQI-V21 |
320*240 |
40.80*30.60 |
46*40.9*2.53 |
3P |
TBD |
4W-SPI |
ILI9342 |
/ | 12 |
21 pins solder type |
|
|
| 2.0 |
TC020GQI-V40 |
960*240 |
40.8 *30.6 |
46.1*40.96*2.53 |
2P |
TBD |
6-bits RGB |
ILI9342 |
/ | 12 |
40 pins connector |
|
|
| 2.2 |
TC022BQS-V14 |
240*320 |
38.14*45.12 |
40.3*54.36*2.2 |
3P |
TBD |
4W-SPI |
ST7789V |
/ | 6 |
14 pin |
|
|
| 2.31 |
TC231TQI-01 |
960*240 |
46.752*35.064 |
55.20*47.55*2.8 |
2P |
TBD |
SPI+6 位 RGB |
ILI9342C |
/ | 12 |
40 pin |
|
|
| 2.4 |
TC024CQS-V40 |
240*320 |
36.72*48.96 |
42.72*60.26*2.20 |
4P |
TBD |
8080-Series MPU |
ST7789V |
with TP |
6 |
40 pins connector |
|
|
| 2.4 |
TC024CQS-V30 |
240*320 |
36.72*48.96 |
42.72*60.26*2.20 |
4P |
TBD |
8080-Series MPU |
ILI9341 |
/ | 6 |
30 pins solder type |
|
|
| 2.4 |
TC024TQS-V14 |
240*320 |
36.72*48.96 |
50*69.2*2.4 |
4P |
TBD |
4-line SPI system |
ST7789V |
/ | 12 |
14 pins solder type |
|
|
| 2.4 |
TC024HQI-V37 |
240*320 |
36.72*48.96 |
42.72*60.26*2.20 |
4P |
TBD |
8080-Series MPU |
ILI9341 |
with TP |
6 |
37 pins solder type |
|
|
| 2.6 |
TC026HQI-V40 |
240*240 |
43.2*43.2 |
47.70*51.35*2.2 |
4P |
TBD |
SPI&MCU |
ILI9341 |
with TP |
ALL |
40PIN |
方屏 |
|
| 2.7 |
TC027GQI-V40 |
960*240 |
33.06*58.80 |
39.1*67.5*2.4 |
3S |
TBD |
SPI&RGB |
ILI8961 |
/ | 6 |
40PIN |
|
|
| 2.8 |
TC028CQI-V40 |
320*320 |
48.96*48.96 |
53.58*57.55*2.5 |
4P |
TBD |
MCU16bit/SPI |
ILI9488 |
with TP |
6 |
40 PIN |
方屏 |
|
| 2.8 |
TC028CQI-V37 |
240*320 |
43.2 *57.6 |
50.00*69.20*2.55 |
4P |
TBD |
16 BITS 80 parallel |
ILI9341 |
with TP |
6 |
37 pins solder type |
|
|
| 2.8 |
TC028CQI-V10 |
240*320 |
57.6*43.2 |
67.5*39.1*2.4 |
4P |
TBD |
4W-SPI |
ILI9341 |
/ | 6 |
10PIN |
|
|
| 2.8 |
TC028CQS-24 |
240*320 |
57.6*43.2 |
67.5*39.1*2.4 |
4P |
TBD |
RGB interface mode |
ST7789V |
with TP |
6 |
24PIN |
|
|
| 2.8 |
TC028HQI-V36 |
240*320 |
43.2 *57.6 |
50.00*69.20*2.55 |
4P |
TBD |
MCU interface mode |
ILI9341 |
/ | 6 |
36pin |
|
|
| 3.0 |
TC030HWS-V40 |
360*640 |
36.72*74.51 |
36.72*65.28*2.1 |
6S |
TBD |
RGB565/MIPI |
ST7701S |
/ | ALL |
40pin |
|
|
| 3.2 |
TC032HSQ-V50 |
240*320 |
48.6*64.8 |
55.4*77.7*2.5 |
6P |
TBD |
16/18bit RGB |
ST7789V |
/ | 6 |
50pin |
|
|
| 3.2 |
TC032HQI-V37 |
240*320 |
48.6*64.8 |
55.04*77.7*2.5 |
6P |
TBD |
8080-Series MPU |
ILI9341 |
/ | 6 |
37 pins connector |
|
|
| 3.5 |
TC035TQG-V54 |
320 * 240 |
70.08 *52.56 |
76.9*63.9*3.26 |
6S |
TBD |
24-bit RGB |
GC3035 |
/ | ALL |
54PIN |
天馬 |
|
| 3.5 |
TC035BQS-V54 |
320 * 240 |
70.08 *52.56 |
76.9*63.9*3.26 |
6S |
TBD |
8-bit RGB |
ST7272A |
/ | ALL |
54PIN |
|
|
| 3.5 |
TC035BQT-01 |
320 * 240 |
70.08 *52.56 |
76.9*63.9*3.26 |
6S |
TBD |
24-bit RGB |
ST7272A |
/ | ALL |
54PIN |
|
|
| 3.5 |
TC035CHI-V14 |
320*480 |
48.96 *73.44 |
54.5*83*2.2 |
6S |
300 |
4line SPI |
ILI9488 |
/ | 12 |
14PIN |
|
|
| 3.5 |
TC035HHS-V10 |
320 *480 |
48.96 *73.44 |
54.50 x 83.00 |
6P |
300 |
3W-SPI |
ST7796 |
/ | 12 |
10PIN |
|
|
| 3.5 |
TC035CHI-Y40 |
320 *480 |
48.96 *73.44 |
54.50 x 83.00 |
6P |
300 |
MCU16bit/SPI |
ILI9488 |
with TP |
12 |
40PIN |
|
|
|
3.5 |
TC035CQI-V39 |
320 *480 |
48.96 *73.44 |
54.50 x 83.00 *2.1 |
6P | 300 |
MCU 8/16/18bit |
ILI9488 |
/ | 12 |
39pin |
|
|
|
3.5 |
TC035CVC-V54 |
640*480 |
70.08 *52.56 |
76.9*63.9*3.3 |
6S | 300 |
Digital 24-bit RGB |
NV3025C |
/ | ALL |
54 pin |
|
|
|
3.5 |
TC035BWE-V50 |
1024*600 |
77.57*45.65 |
87.1*55.5*2.9 |
6S | 350 |
RGB24位 |
TBD |
/ | ALL |
40PIN |
超高清 |
|
|
3.5 |
TC035GQS-V40 |
320*240 |
70.08 *52.56 |
76.9*63.9*4.35 |
6S | 350 |
8080MCU 8/16Bit SPI |
SSD2119 |
RTP |
6 |
40PIN |
|
|
|
3.5 |
TC035HLQS-V54 |
320*240 |
70.08 *52.56 |
76.9*63.9*3.26 |
6S | 350 |
8 bit RGB |
ST7272A |
/ | 12 |
54 pin |
|
|
|
3.5 |
TC035LQS-V50 |
320 240 |
70.08 *52.56 |
74.84*86.84*4.13 |
2*3 | 350 |
MCU |
SSD2119 |
TP |
6 |
50 pin |
|
|
|
3.5 |
TC035NC111-GP |
320 *240 |
70.08 *52.57 |
76.9*63.9*3.3 |
6S | 350 |
Digital 24-bit RGB |
HX8238-D |
/ | 6 |
54 pin |
|
|
|
3.5 |
TC035BFS-V50 |
1920*1080 |
77.76*43.74 |
87.1*56.8*2.5 |
6S | 350 |
RGB24位 |
TBD |
/ | ALL |
50PIN |
超高清 |
|
|
3.5 |
TC035HQS-V40 |
320*240 |
70.08 *52.56 |
76.9*63.9*3.3 |
6S | 250 |
RGB 5654 |
ST7272A |
/ | ALL |
54 pins connector |
帶蓋板 |
|
|
3.5 |
TC035GQH-V54 |
320*240 |
70.08 *52.56 |
76.9*63.9*3.3 |
6S | 250 |
RGB 24 bit |
HX8238-D |
/ | 6 |
54 pins connector |
|
|
|
3.8 |
TC038BWQS-V40 |
480*128 |
95.04 x 14.21 |
105.5*25.6*2.95 |
2*5 | 400 |
RGB 24 bit data |
ST7282 |
/ | ALL |
40 pin |
長條屏 |
|
|
3.9 |
TC039HWQS-V40 |
480*128 |
95.04 x 25.34 |
105.5*40.64*2.95 |
2*5 | 400 |
RGB 24 bit data |
SC7283 |
CTP |
ALL |
40 pin |
長條屏 |
|
|
4.0 |
TC040HWS-V25 |
480*800 |
51.84*86.4 |
57.14*96.85*2.2 |
6S | 320 |
RGB 24 bit |
ILI9806E |
/ | ALL |
25 pins solder type |
|
|
|
4.3 |
TC043BWH-K40 |
800*480 |
95.04*53.856 |
105.5*67.2*2.9 |
5*2 | 400 |
RGB 24 bit |
ST7282 |
/ | 6 |
40 pin |
|
|
|
4.3 |
TC043CWVO-V40 |
480*272 |
95.04*53.856 |
105.5*67.2*4.2 |
7S | 400 |
RGB 24 bit |
ST7282 |
/ | 6 |
40 pin |
|
|
|
4.3 |
TC043HVH-01 |
480*800 |
95.04*53.86 |
105.5*67.2*3.3 |
8*2 | 400 |
RGB 24 bit |
HX8264-D03 +HX8664-B |
/ | ALL |
40 pin |
|
|
|
4.3 |
TC043HWS-Y40 |
480 *272 |
95.04 ×53.856 |
105.50X67.20X3.0 |
5*2 | 500 |
RGB 24 bit |
SC7283 |
CTP |
ALL |
41 pin |
|
|
| 4.3 |
TC043IWS-01 |
480 *272 |
95.04 ×53.856 |
105.50X67.20X3.0 |
7S | 350 |
RGB 24 bit |
ST7282 |
/ | 12 |
40 pin |
|
|
|
4.3 |
TC043VHH-Y40 CTP |
480*800 |
95.04 ×53.856 |
105.50*67.20*3.0 |
2*5 |
500 |
RGB 24 bit |
HX8264 HX6126 |
/ | ALL |
40 pin |
|
|
|
4.3 |
TC-43480272-CTP- |
480 *272 |
95.04×53.856 |
105.50x67.20x3.0 |
5*2 | 500 |
RGB 24 bit |
ST7282 |
/ | 12 |
40 pin |
|
|
|
4.3 |
TC043WCS-40 |
480*272 |
95.04 ×53.856 |
105.50*67.20*3.1 |
7S | 300 |
RGB 24 bit |
ST7282 |
/ | 12 |
40 pin |
|
|
|
4.3 |
TC043CWH-V40 |
480*272 |
95.04X53.856 |
105.5*67.2*4.2 |
7S | 300 |
RGB 24 bit |
HX8257A |
with TP |
6 |
40 pins connector |
|
|
|
4.3 |
TC043CWO-V40 |
480*272 |
95.04X53.856 |
105.5*67.2*3.1 |
7S | 550 |
RGB 24 bit |
OTA5180 |
/ | 6 |
40 pins connector |
|
|
|
4.3 |
TC043IWS-V40 |
480*272 |
95.04*53.856 |
105.5*67.2*3.0 |
7S | 200 |
RGB 24 bit |
ST7282 |
/ | 12 |
40 pins connector |
|
|
|
4.3 |
TC050IWQ0-V40 |
480*272 |
110.8*62.8 |
120.7*75.8*3 |
6*2 | 350 |
RGB 24 bit |
ILI6480 |
with TP |
6 |
40 pins connector |
|
|
|
4.3 |
TC043BWS-S40 |
800*480 |
95.04×53.856 |
102.5*67.2*3.0 |
5*2 | 300 |
RGB 24 bit |
ST7262 |
/ | ALL |
40pin |
|
|
|
5.0 |
TC050HWVS-S40 |
800*480 |
108*61.8 |
102.70*75.90*3.05 |
6*3 | 350 |
RGB 24bit |
ST7262 |
/ | ALL |
40pin |
|
|
|
5.0 |
TC050BFS-Y40 |
480*854 |
110.53*62.56 |
126.93*69.7*3.9 |
6*3 | 350 |
RGB 24bit |
ST7701S |
CTP |
ALL |
40pin |
|
|
|
5.0 |
TC050IWI-V40 |
800*480 |
57.61*102.48 |
63.4*113.28*2.0 |
5.2 | 350 |
RGB 24bit |
6122/5960 |
/ | 12 |
40 pin |
|
|
|
5.0 |
TC050WCS-40 |
480 *272 |
480 *272 |
120.7x75.8x3.0 |
6.2 | 350 |
RGB 24bit |
6122/5960 |
/ | 12 |
40 pin |
|
|
|
5.0 |
TC050IQI-V40-01 |
800*480 |
108*64.8 |
120.7*75.8*3.0 |
6*2 | 500 |
RGB 24bit |
6122/5960 |
/ | 12 |
40pins connector |
|
|
|
5.0 |
TC050IWI-V40 |
800*480 |
108*64.8 |
120.7*75.8*3.0 |
6*2 | 500 |
RGB 24bit |
6122/5960 |
/ | 12 |
40pins connector |
|
|
| 7.0 |
TC070BWE-V50 |
800*480 |
154.08*85.92 |
164.9*100.0*3.5 |
6*2 | 350 |
RGB 24bit |
TBD |
/ | 12 |
40pins connector |
|
|
| 7.0 |
TC070BWE-H30 |
1024*600 |
154.2144×85.920 |
163.97.0×2.60 |
7*3 | 350 |
RGB 24bit |
TBD |
/ | ALL |
30 pin |
|
|
|
8.0 |
TC080BFI-V31 |
800*1280 |
107.64*172.224 |
114.6*184.104*2.6 |
7.3 | 350 |
mipi Interface |
TBD |
/ | ALL |
31 pin |
|
|
|
10.1 |
TC101IWE-H30 |
1024*600 |
222.72 x125.28 |
235 *143 *3.0 |
9.3 | 220 |
mipi Interface |
EK79007 EK 73215 |
/ | ALL |
30 pin |
|
|
|
10.4 |
TC104BWS-V50 |
1024*100 |
264.19 x25.8 |
274.92 *41.5 *3.5 |
9*4 | 500 |
RGB 24 bit |
TBD | / | ALL |
40 pin |
|
|
